SPECIFICATIONS

Application: Desktop

Back I/O Ports: VGA (D-Sub),DVI-A,HDMI 1.0

Battery Included: No

Brand Name: XINRENCHONG

Certification: weee,UL

Chipset: AMD B450

Chipset Manufacturer: AMD

Form Factor: CeB,Micro-ATX

High-concerned chemical: None

Maximum Ram Capacity: 32 GB

Memory channel: Double

Number Of Memory Slots: 4

Number of M.2: 1

Number of PCI: 0

Number of PCIe x 1: 1

Number of PCIe x 16: 2

Number of PCIe x 4: 0

Number of SATA Ports: 4

Onboard LAN: 1x RJ45

Origin: Mainland China

PCI - E standards: PCI-E 3.0

Package: Yes

Processor compatibility: AMD Others

Quality Certification: ce,ROHS

RAID Supported: Yes

SATA RAID: 0

Socket Type: AM4

Special Features: NONE

Storage Interface Type: SATA 3

Support Memory Type: DDR4

Support USB Type: USB 2.0,USB 3.1 Gen1,USB 3.1 Gen2

Usage Scenario: Gaming,Audio & Video,Office,Design,others

With CPU: No

1、 Core specifications

CPU slot: AMD AM4

Chipset: AMD B450

Plate type: m-ATX (24.4 × 24.0 cm)

Power supply: 24 pin ATX+8 pin 12V (supports CPU overclocking)

2、 Processor support (requires BIOS update)

Ryzen 5000 Series: 5000/5000G/4000G

Ryzen 3/2/1 generation: Full range (including APU)

Speed Dragon Series: Speed Dragon APU (Vega Core Display)

Maximum core: 16 cores (such as R9 5950X)

3、 Memory

Slot: 4xDDR4 DIMM (dual channel)

Maximum capacity: 128GB (32GB x 4)

Frequency: DDR4 4400 (O.C.)/3466 (O.C.)/3200 (O.C.)/2666/2400/2133 MHz

Features: Supports XMP, Non ECC, Unbuffered

4、 Storage interface

M.2：1 × M.2 Socket 3（M Key）

Supports PCIe 3.0 x4 (NVMe 32Gbps)+SATA mode

Size: 2242/2260/2280

SATA：4 × SATA 6Gb/s（6.0 Gb/s）

5、 Expansion slot

Graphics card: 1 x PCIe 3.0 x16 (full speed x16, reinforced with Safe Slot)

Expansion: 2 x PCIe 2.0 x1

6、 Display output (nuclear display)

HDMI 2.0b： 4K@60Hz

DVI‑D：1920× 1200@60Hz

VGA（D‑Sub）：1920× 1200@60Hz

7、 Network and Audio

Network card: Realtek RTL8111H, 1Gbps wired

Audio: Realtek ALC887-VD2, 8-channel high-definition audio (Japanese capacitor, channel isolation)

8、 USB interface

Rear:

USB 3.2 Gen 2（10Gbps）：1 × Type‑A

USB 3.2 Gen 1（5Gbps）：4 × Type‑A

USB 2.0：2 × Type‑A

built-in:

USB 3.2 Gen 1 front: 1 set (2 ports)

USB 2.0 front: 2 sets (4 ports)

9、 Other interfaces

Fan: 3 × 4-pin PWM fan interface (including CPU fan)

RGB: 1 x Aura Sync RGB Pin

TPM: 1 x TPM pin

COM/LPT/S/PDIF: 1 set of pins each

10、 Characteristics

DIGI+digital power supply: supports CPU/memory overclocking

Fan Xpert 2+: Intelligent Fan Speed Control

5X Protection III: Hardware Protection

UEFI BIOS: EZ Flash 3 Online Upgrade
